22-1832-13 5
Product Specifications
Model No. 1 4TWR5042G1 4TWR5049E1 4TWR5061E1
Electrical Data V/Ph/Hz 2 208/230/1/60 208/230/1/60 208/230/1/60
Min Cir Ampacity 23 28 36
Max Fuse Size (Amps) 40 50 60
Compressors
CLIMATUFF
® -
SCROLL CLIMATUFF
® -
SCROL CLIMATUFF
® -
SCROL
RL AMPS - LR AMPS 16.7 - 112 21.8 - 117 26.4 - 134
Outdoor Fan FL Amps 0.74 1.00 2.80
Fan HP 1/8 1/5 1/3
Fan Dia (inches) 26.6 27.6 227.6
Coil Spine Fin™ Spine Fin™ Spine Fin™
Refrigerant R-410A 9/14-LB/OZ 13/10-LB/OZ 13/12-LB/OZ
Line Size - (in.) O.D. Gas 3 3/4 7/8 1-1/8
Line Size - (in.) O.D. Liquid 3 3/8 3/8 3/8
Dimensions H x W x D (Crated)
42 x 35.1 x 38.7 51 x 35.1 x 38.7 51 x 35.1 x 38.7
Weight - Shipping 277 331 332
Weight - Net 243 294 295
Start Components NO NO YES
Sound Enclosure YES NO NO
Compressor Sump Heat YES YES YES
Optional Accessories: 4
Anti-short Cycle Timer TAYASCT501A TAYASCT501A TAYASCT501A
Evaporator Defrost Control A/C AY28X084 AY28X084 AY28X084
Rubber Isolator Kit BAYISLT101 BAYISLT101 BAYISLT101
Hard Start Kit Scroll BAYKSKT263 BAYKSKT263
Extreme Condition Mounting Kit BAYECMT004 BAYECMT004 BAYECMT004
Snow Leg - Base & Cap 4" High BAYLEGS002 BAYLEGS002 BAYLEGS002
Snow Leg - 4" Extension BAYLEGS003 BAYLEGS003 BAYLEGS003
Seacoast Kit BAYSEAC001 BAYSEAC001 BAYSEAC001
Refrigerant Lineset 5 TAYREFLN7* TAYREFLN3* TAYREFLN3*
1 Certified in accordance with the Air-Source Unitary Heat Pump Equipment certification program which is based on AHRI Standard 210/240.
2 Calculated in accordance with N.E.C. Only use HACR circuit breakers or fuses.
3 Standard line lengths - 60'. Standard lift - 60' Suction and Liquid line.
For Greater lengths and lifts refer to refrigerant piping software Pub# 32-3312-0
†
. (
†
denotes latest revision)
4 For accessory description and usage, see page 5.
5 * = 15, 20, 25, 30, 40 and 50 foot lineset available.
