Trane XR15 User Manual

4 22-1832-13
Product Specifications
Model No. 1 4TWR5018G1 4TWR5024G1 4TWR5030G1 4TWR5036G1
Electrical Data V/Ph/Hz 2 208/230/1/60 208/230/1/60 208/230/1/60 208/230/1/60
Min Cir Ampacity 9 11 15 18
Max Fuse Size (Amps) 15 15 25 30
Compressors CLIMATUFF
®
CLIMATUFF
®
CLIMATUFF
®
CLIMATUFF
®
RL AMPS - LR AMPS 6.4 - 38.6 8.3 - 58 11.3 - 68.2 13.2 - 63
Outdoor Fan FL Amps 0.70 0.74 0.92 1.00
Fan HP 1/8 1/8 1/5 1/5
Fan Dia (inches) 23 23 27.5 27.5
Coil Spine Fin™ Spine Fin™ Spine Fin™ Spine Fin™
Refrigerant R-410A 5/14-LB/OZ 7/02-LB/OZ 8/02-LB/OZ 7/13-LB/OZ
Line Size - (in.) O.D. Gas 3 5/8 5/8 3/4 3/4
Line Size - (in.) O.D. Liquid 3 3/8 3/8 3/8 3/8
Dimensions H x W x D (Crated) 34 x 30.1 x 33 38 x 30.1 x 33 38.4 x 35.1 x 38.7 37.9 x 35 x 37.9
Weight - Shipping 204 236 273 261
Weight - Net 176 208 239 227
Start Components YES YES YES YES
Sound Enclosure NO NO YES YES
Compressor Sump Heat YES YES YES YES
Optional Accessories: 4
Anti-short Cycle Timer TAYASCT501A TAYASCT501A TAYASCT501A TAYASCT501A
Evaporator Defrost Control A/C AY28X084 AY28X084 AY28X084 AY28X084
Rubber Isolator Kit BAYISLT101 BAYISLT101 BAYISLT101 BAYISLT101
Hard Start Kit Scroll
Extreme Condition Mounting Kit BAYECMT004 BAYECMT004 BAYECMT004 BAYECMT004
Snow Leg - Base & Cap 4" High BAYLEGS002 BAYLEGS002 BAYLEGS002 BAYLEGS002
Snow Leg - 4" Extension BAYLEGS003 BAYLEGS003 BAYLEGS003 BAYLEGS003
Seacoast Kit BAYSEAC001 BAYSEAC001 BAYSEAC001 BAYSEAC001
Refrigerant Lineset 5 TAYREFLN950 TAYREFLN950 TAYREFLN7* TAYREFLN7*
1 Certified in accordance with the Air-Source Unitary Heat Pump Equipment certification program which is based on AHRI Standard 210/240.
2 Calculated in accordance with N.E.C. Only use HACR circuit breakers or fuses.
3 Standard line lengths - 80'. Standard lift - 60' Suction and Liquid line.
For Greater lengths and lifts refer to refrigerant piping software Pub# 32-3312-0
†
. (
†
denotes latest revision)
4 For accessory description and usage, see page 5.
5 * = 15, 20, 25, 30, 40 and 50 foot lineset available.
General
Data
63 125 250 500 1000 2000 4000 8000
4TWR5018G 75 52.3 57.8 62.4 67.2 69.4 67.2 59.6 52.5
4TWR5024G 75 50.3 55 58.6 65.3 69.5 64.5 58.6 50.8
4TWR5030G 75 48.8 55.4 60.1 66.4 67.4 63.9 60.2 53.5
4TWR5036G 75 54.5 55.1 58.3 67 69.8 65.9 59.7 49.1
4TWR5042G 75 55.1 52 59.3 64.9 67.2 63.5 60.4 47.6
4TWR5049E 75 43.7 51.2 54.5 61 61.5 57.1 51.3 40.7
4TWR5061E 75 33.1 56.2 60.1 64.4 66 59.5 54.2 43.5
Note: Rated in accordance with AHRI Standard 270-2008.
SOUND POWER
LEVEL [dB(A)]
A-weighted Sound Power Level [dB(A)]
MODEL
A-WEIGHTED FULL OCTAVE SOUND POWER LEVEL dB - [dB(A)] High Stage

Trane XR15 Specifications

General

SEER	Up to 16.00
Refrigerant	R-410A
Energy Star	Yes
Heating Capacity (BTU/h)	18, 000-60, 000
HSPF	9.0
Compressor	Climatuff®
Sound Level	72 dB
Cooling Capacity	1.5 - 5 ton
Warranty	10-year limited warranty on compressor and outdoor coil
