Trane XR15 User Manual

 6 22-1832-13
General
Data
AHRI Standard Capacity Rating Conditions
AHRI STANDARD 210/240 RATING CONDITIONS —
(A) Cooling80°FDB,67°FWBairenteringindoorcoil,
95°FDBairenteringoutdoorcoil.
AHRI STANDARD 270 RATING CONDITIONS —(Noise
ratingnumbersaredeterminedwiththeunitincoolingopera-
tion.)StandardNoiseRatingnumberisat95°Foutdoorair.
Accessory Description and Usage
Anti-Short Cycle Timer—Solidstatetimingdevicethat
preventscompressorrecyclinguntil5minuteshaveelapsed
aftersatisfyingcallorpowerinterruptions.Useinareawith
questionablepowerdelivery,commercialapplications,long
lineset,etc.
Evaporator Defrost Control—SPSTTemperatureactuated
switchthatcyclesthecondenseroffasindoorcoilreaches
freeze-upconditions.Usedforlowambientcoolingto30°F
withTXV.
Rubber Isolators —5largerubberdonutstoisolatecon-
densingunitfromtransmittingenergyintomountingframeor
pad.Useonanyapplicationwheresoundtransmissionneeds
tobeminimized.
Hard Start kit —Startcapacitorandrelaytoassistcompres-
sormotorstartup.Useinareaswithmarginalpowersupply,
onlonglinesets,lowambientconditions,etc.
Extreme Condition Mount Kit —Bracketkitstosecurely
mountcondensingunittoaframeorpadwithoutremoving
anypanels.Useinareaswithhighwinds,oroncommercial
rooftops,etc.

Trane XR15 Specifications

General

SEER	Up to 16.00
Refrigerant	R-410A
Energy Star	Yes
Heating Capacity (BTU/h)	18, 000-60, 000
HSPF	9.0
Compressor	Climatuff®
Sound Level	72 dB
Cooling Capacity	1.5 - 5 ton
Warranty	10-year limited warranty on compressor and outdoor coil
