14
Pub. No. 22-5128-02
69-1216
AM
PM
SUN MON TUE WED THU FRI SAT COOL ON HEAT ON
WAKE LEAVE RETURN NIGHT TEMPORARY UNOCCUIPIED
SET
PT
AM
PM
SUN MON TUE WED THU FRI SAT COOL ON HEAT ON
WAKE LEAVE RETURN NIGHT TEMPORARY UNOCCUIPIED
SET
PT
AM
PM
SUN MON TUE WED THU FRI SAT COOL ON HEAT ON
WAKE LEAVE RETURN NIGHT TEMPORARY UNOCCUIPIED
SET
PT
AM
PM
SUN MON TUE WED THU FRI SAT COOL ON HEAT ON
MORNING LEAVE RETURN SLEEP TEMPORARY UNOCCUIPIED
SET
PT
At 4:00 AM
Recovery Begins
At 5:00 AM
Recovery
Continues
At 6:00 AM
Recovery
Continues
At 7:00 AM System
Operating in Comfort Mode
ENERGY
SAVINGS
PERIOD
RECOVERY FROM ENERGY SAVINGS
COMFORT
PERIOD
TIME
TEMPERATURE
THE THERMOSTAT USES THE SAME SCHEME TO RETURN GRADUALLY
TO LOWER COMFORT TEMPERATURE DURING THE COOLING SEASON.
