21
Bluetooth (“B”) Menu Descriptions
This section provides more detailed descriptions of the selections found in the Bluetooth Menu
Chart. Factory-set defaults are shown in bold with a checkmark; ().
CODE/NAME DESCRIPTION SELECTION LIST
B1
Adjust Load
Cell (Corner)
#1 Factor
This parameter allows you to adjust (‘tweak’) the digital corner com-
pensation factory for load cell/corner #1. Be sure to perform a digital
corner calibration (via B10) before using this procedure. Pressing the
ZERO key to scroll down one level begins the programming se-
quence.
Key-in
0 to 6.5535
1.0000
√√
B2
Adjust Load
Cell (Corner)
#2 Factor
This parameter allows you to adjust (‘tweak’) the digital corner com-
pensation factory for load cell/corner #2. Be sure to perform a digital
corner calibration (via B10) before using this procedure. Pressing the
ZERO key to scroll down one level begins the programming se-
quence.
Key-in
0 to 6.5535
1.0000
√√
B3
Adjust Load
Cell (Corner)
#3 Factor
This parameter allows you to adjust (‘tweak’) the digital corner com-
pensation factory for load cell/corner #3. Be sure to perform a digital
corner calibration (via B10) before using this procedure. Pressing the
ZERO key to scroll down one level begins the programming se-
quence.
Key-in
0 to 6.5535
1.0000
√√
B4
Adjust Load
Cell (Corner)
#4 Factor
This parameter allows you to adjust (‘tweak’) the digital corner com-
pensation factory for load cell/corner #4. Be sure to perform a digital
corner calibration (via B10) before using this procedure. Pressing the
ZERO key to scroll down one level begins the programming se-
quence.
Key-in
0 to 6.5535
1.0000
√√
B6
Restore factory
calibration
Restores factory calibration data. Scrolling down with the ZERO key
one level begins the procedure.
Press ZERO key
to begin sequence
B8
RFTM Auto
Power Off
This parameter allows you to set the automatic power off timeout for
the TI-500 RFTM.
"0" = Always on
"1" = 30 minutes
“2” = 1 hour
“3” = 2 hours
0
1
2
3
√√
B9
RFTM Low
Battery Force
Off
This parameter allows you to set the automatic power off timeout in
minutes for the TI-500 RFTM during a low battery condition. Pressing
the ZERO key to scroll down one level begins the programming se-
quence.
Key-in
0 to 99
10
√√
B10
Digital Corner
Calibration
Places indicator into the digital corner calibration routine. Scrolling
down with the ZERO key one level begins the procedure.
Press ZERO key
to begin sequence
