Transcell Technology TI-500 RF Series Installer Manual

8
Electrical Connections
The top cover must first be removed to make the appropriate connections to the weigh platform.
To remove the top cover, simply remove the six (6) screws that secure it to the enclosure and
set aside.
Caution! Disconnect power source from junction box prior to removing top cover.
Note: If the optional control panel was ordered, you need not make connections to the
LCT-1 for power supply, serial device or on/off control

Transcell Technology TI-500 RF Series Specifications

General

Brand	Transcell Technology
Model	TI-500 RF Series
Category	Touch Panel
Language	English
