CONFIGURATION
OVERVIEW
The indicator contains two main
configuration
m
enus:
The Setup (“F”) menu, which configures the ind
ic
ator to your weigh platform
T
he User (“A”) menu, which configures the serial communication port and enab
les some user
options
The Setup and User menus consist of several menu sele
c
tions, each
with its
own sub
-
menu of selections
or programming procedures
.
To
configure the indicator you must first enter the appropriate menu mode.
Once there, four of the front panel keys become directional navigators to move around in the menus, and
one key is used to sav
e or SET the selections
.
ACCESSING THE MENUS
To access the Setup (“F) menu:
1.
Power off the indicator.
2.
Press and hold the “SET” key for about three seconds while turning the unit back on.
The
display
shows ” F 1” to indicate that you are in Setup Menu
mode.
3.
Use the navigation keys shown in the
below
to move
through the menu.
SETUP MODE KEY FUNCTIONS
ZERO
GROSS
NET
TARE
PRINT
SET
UNITS
To access the User (“A) menu:
1.
Enter the Setup (“F”) menu.
2.
Use the right or left directional keys shown
above
to move right or left in the Setup (“
F”) menu
until the indicator shows ” A 1”.
