Transcell Technology TI-500E - User (A) Menu Descriptions

10
7. If there is a selection list, scroll thru the available parameter settings, use the TARE (left) or
PRINT (right) keys. Otherwise, use the arrow keys to adjust the displayed value to the new
value.
8. Once the setting you want is displayed on the screen, press the NET/GROSS (set) key to
save this value.
9. Press the UNITS (up) key to return to the parameter level, e.g., “A 1”.
User (“A”) Menu Descriptions
This section provides more detailed descriptions of the selections found in the User Menu Chart.
Factory-set defaults are shown in bold with a checkmark; (√).
CODE/NAME
DESCRIPTION
SELECTION LIST
A1
Baud Rate
Selects the baud rate for data transmission through the serial (COM)
port.
1200, 2400, 4800,
9600 , 19200
A2
Data Bits and
Parity
Selects the number of data bits and parity of serial transmission.
"8n" = 8 data bits with no parity bit and one stop bit
"7o" = 7 data bits with odd parity bit and one stop bit
"7E" = 7 data bits with even parity bit and one stop bit
"7n" = 7 data bits with no parity bit and two stop bits
8n
7o
7E
7n
A3
Mode of Serial
Transmission
Selects how data will be sent out of the serial (COM) port to a printer
or computer:
"C" = Continuous mode; send data continuously
"d" = Demand mode; send data when a PRINT command is
issued by a host.
C
d
A4
Display Check
Actuates the function that illuminates all digit segments, decimal
points, and LCD annunciators in a test sequence. Pressing the ZERO
key to scroll down one level begins the test sequence.
Press ZERO key
to begin sequence
A5
Disable the
UNITS Key
Allows the UNITS key to be disabled so that an operator cannot acci-
dentally press the key and change the displayed units (lb/kg).
"0" = Disable the UNITS key "1" = Enable the UNITS key
0
1
A6
Serial (COM)
Port Output
String
Selects the output string of the serial (COM) port: Refer to Serial Port
Information for more details.
"0" = Full Duplex (Condec string)
"1" = Text Print Ticket (MP-20)
“2” = Text Print Ticket with Auto Label Feed (MP-20)
"3" = 6L.BAS = 6 lines, Label
"4" = 6P.BAS = 6 lines, Paper (Default)
"5" = 6LB.BAS = 6 lines, Label, Barcode
"6" = 6PB.BAS = 6 lines, Paper, Barcode
"7" = CUSTOM.BAS
0
1
2
3
4
5
6
7
