Transcell Technology TI-500E - Entering the User (“A”) Menu; User (“A”) Menu Descriptions

9
CODE/NAME
DESCRIPTION
SELECTION LIST
F9
Display
Divisions
Sets the interval value. Use together with F10.
1
2
5
F10
Decimal Pt.
Sets the decimal point value. Use together with F9.
0 0.0
0.00 0.000
0.0000 00
F16
Zero Calibra-
tion
Places indicator into live zero-calibration mode. Scrolling down with
the ZERO key one level begins the procedure.
Press ZERO key
to begin sequence
F17
Span Calibra-
tion
Places indicator into live span calibration mode. Scrolling down with
the ZERO key one level begins the procedure.
Press ZERO key
to begin sequence
F18
View Calibra-
tion Data
Activates the function that allows you to view calibration values.
Scrolling down with the ZERO key one level begins the procedure.
Press ZERO key
to begin sequence
F19
Key-in Zero
Allows you to key-in a known zero calibration value. Scrolling down
with the ZERO key one level begins the procedure.
Press ZERO key
to begin sequence
F20
Key-in Span
Allows you to key-in known span calibration values. Scrolling down
with the ZERO key one level begins the procedure.
Press ZERO key
to begin sequence
F21
Factory Reset
This sub-menu will reset all parameters in the “F” and “A” menu to the
default settings. It will not overwrite any previously saved calibration
data. USE WITH CAUTION!
Press the ZERO
key twice to exe-
cute
F24
Piece Count
Enable
Used to enable or disable the piece count feature. This feature must
be disabled for commercial applications.
"0" = Disable piece count "1" = Enable piece count
0
1
Entering the User (“A”)
1. Switch off the indicator
2. Locate the slide switch on the rear cover and move it to the opposite position.
NOTE: A metal plate held on by two drilled-head screws conceals the slide switch.
3. Switch on the indicator. The display shows “F 1” to indicate that you are in Setup Menu
mode.
4. Use the TARE (left) or PRINT (right) keys to move right or left in the Setup (“F”) menu until
the indicator shows “A 1”.
5. Move from one “A” parameter to the next by using the TARE (left) or PRINT (right) keys. For
example, to go from A1 to A2, press the PRINT key. To go from A2 back to A1, press the
TARE key.
6. Once you have arrived at the proper “A” menu parameter, e.g. “A 1”, press the
ZERO (down) key once to arrive at the selection level. The indicator displays the current pa-
rameter setting.
