1-1 CAM GROUP T6-1-10006
T6-1-10007
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
T6-1-10006 Cam Group (For 1PH) 1
T6-1-10007 Cam Group (For 3PH) 1
1 T6-1-10110 Tension Cam 1
2 T6-1-10120 Cam Shaft End Plate 1
3 T6-1-10130 Limit Cam (LS1) 1
4 T6-1-10140 Limit Switch Contactor A (LS3) 1
5 T6-1-10150 Limit Switch Contactor B (LS2) 1
6 KYA070720 Key, 7x7x20 2
7 T6-6-30004 Gear Box Pulley 1
8 T6-1-10180 Limit Switch Bracket 1
9 BR6205ZZ Bearing, 6205ZZ 2
10 T6-1-10200 V-Belt (A26) (For 1PH) 1
T6-1-10201 V-Belt (A25) (For 3PH) 1
11 T6-6-10180 Magnet Brake 1
41 T6-1-11000 Gear Box 1
42 T6-1-12000 Cam Ass'y 1 SEE PAGE 4
51 HBS0845H HBS, M8x45 (H) 4
52 HBS0825 HBS, M8x25 1
53 HBS0615 HBS, M6x15 2
54 HSS0610 HSS, M6x10 8
55 PW08B PW, M8 (B) 4
56 SW08 SW, M8 1
57 SW06 SW, M6 2
61 SW04 SW, M4 4
62 PMS0408 PMS, M4x8 4
-3-
11/27/08
