-38-
VIII. CONTROL PARAMETERS
VIII. f - UNDERCOUNTER PARAMETER SETTINGS (MIT II Control Version):
Control
Parameter UF1 UF2 UP1 UP2
ADR 2 2 2 2
BAU 9.6 9.6 9.6 9.6
NAF ON ON ON ON
SPH 0.1 38.1 38.1 38.1
SPL -4 33.8 33.8 33.8
SHL -0.31 36 36 36
SHH 0.1 40 40 40
SLL -6.2 32 32 32
SLH -4 34 34 34
RO 0 0 0 0
HI 5 41 41 41
LO -10 30.2 30.2 30.2
SCL F F F F
HAD 15 15 15 15
LAD 2 2 2 2
AC 3 3 3 3
DEF GAS GAS OFF OFF
IBD 4.0 4.0 1.0 1.0
DDC 20 20 10 10
CDE 75 75 45.1 45.1
DDE 5 2 2 2
BDD 1 1 0 0
BSD -10 32 32 32
ODD 10 10 10 10
SD
Starts a new defrost cycle at any time or stops a current defrost cycle.
CFA OFF OFF N/A OFF
CCR 20 20 N/A 20
CDL 220.1 220.1 N/A 220.1
DOA OFF OFF N/A OFF
DAD 15 15 N/A 15
APD 2 2 2 2
ATD 10 10 N/A 10
AAS OFF OFF N/A OFF
CL Set the hours and minutes in military time.
DAY Set the year, month, day of the month and day of the week.
DS ON ON ON ON
DL1 OFF OFF OFF OFF
DL2 OFF OFF OFF OFF
DL3 OFF OFF OFF OFF
DL4 OFF OFF OFF OFF
DCF 100 100 100 100
CON 19 19 11 11
COF 7 7 10 10
EL
Will display evaporator coil temp in real time every time an arrow is pressed.
DL
Will display discharge line temp in real time every time an arrow is pressed.
CB
Will display cabinet air temp in real time every time an arrow is pressed.
PLn
Will display power line voltage in real time every time an arrow is pressed.
RCO
Turns ON/OFF the compressor relay for 10-seconds or until an arrow is pressed.
RdF
Turns ON/OFF the defrost relay for 10-seconds or until an arrow is pressed.
RFA
Turns ON/OFF the blower relay for 10-seconds or until an arrow is pressed.
RDH
Turns ON/OFF the door heater triac for 10-seconds or until an arrow is pressed.
PRO Set the controller in receiving mode for programming.
CEP Clear all controller memories and reloads the factory default parameters.
REF
Firmware revision in the format X9.9 (X=version, 9=major revision, 9=minor revision).
