8. Insert M.2 SSD MODULE (optional)
Follow the step-by-step instructions shown to insert the SSD into the SSD extension
slot. Make sure that the computer is switched off before inserting the SSD.
i
ADVICE
The Surfbook E11B is only compatible with an SSD module with form factor
M.2 2242 in version B & M key and B key.
Step 1: Unscrew SSD extension slot
Use a screwdriver to loosen the screw in the cover
of the SSD extension slot. Remove and retain the
screw.
Step 2: Open SSD extension slot
Open the cover of the SSD extension slot by
inserting a small lever into the screw opening and
lifting the cover. Never use sharp or sharp-edged
tools. Then use your ingers to remove the cover.
A second screw base becomes visible once you
open the SSD extension slot. Loosen the screw in
the screw base; remove and retain it.
