Step 3: Insert SSD
Align the SSD before inserting it into the
extension slot. The semicircular recess of
the SSD points towards the screw base and
the gold-coloured contacts of the SSD point
towards the contacts in the SSD extension slot.
Insert the SSD slightly diagonally into the SSD
extension slot.
i
ADVICE
The SSD can only be inserted in one direction. Depending on the connection type
that your device features, the SSD may have to be rotated along its longitudinal
axis to it correctly.
You know the SSD has been inserted correctly if the semicircular recess is
secured irmly to the screw base. Use the screw removed in step 2 to tighten the
SSD in the deeper-lying screw base.
Step 4: Seal SSD extension slot
Use the cover to seal the SSD extension slot. Then use the screw removed in
step 1 to screw together the SSD extension slot.
Start your computer. The control panel will now display the SSD as a new
storage medium. The SSD is now ready for use.
