TREND LOCK/JIG - Description of Parts; Jig Components Identification

LOCK/JIG
-5-
DESCRIPTION OF PARTS
Use the drawing below as
a guide to assemble
the jig.
A
B
F
C
D
E
G
H
I
L
Q
M
P
TOP VIEW
O
J
K
N
A Jig body
B Adjustable lever
fixing stud
C Clamp bar (datum)
D Adjustable lever
washer
E Adjustable lever
M8
F Spacer finger
fixing stud
G Spacer finger
H Spring washer
I Mini knob M5
J Guide bush collar
16mm to 30mm
K Collar park
L Mortise template
M Face plate
template
N Clamping knob
with pad
O Jig template
aperture recess
P Central aperture
Q Line-up Template
Ensure jig is clean
and free of oil
before use.
