TRENDnet TE100-PCI User Manual

Fiber Ethernet Adapter
User’s Guide 11
檔名: pcifxp.doc
原作者: Carrie Chen
列印時間: 1/31/2003 3:06 PM
Cabling Requirements
For cabling requirements and maximum segment distance when
connecting the Fiber Adapter to your network, please refer to the
Ordering Information on page 18.
TX c o n n e c t o r
Insert the other end of c able
into the 'receive' (RX) connector
on network hub or switch
RX c o n n e c t o r
Insert the other end of cable
into the 'transmit' (TX) connec tor
on network hub or switc
h
(SC type connector fiber cable)
Figure 4: Connecting to your network

TRENDnet TE100-PCI Specifications

General

Brand	TRENDnet
Model	TE100-PCI
Category	Adapter
Language	English
