Page #7 background image
Fiber Ethernet Adapter
User’s Guide 7
檔名: pcifxp.doc
原作者: Carrie Chen
列印時間: 1/31/2003 3:06 PM
Hardware Installation
Installing Fiber Adapter into PCI slot
Step 1: Turn off the power to the PC.
Step 2: Remove any metal decorations from your hands and wrists.
Step 3: Remove the cover from your PC.
Step 4: Locate an empty, non-shared bus mastering 32-bit PCI slot and remove
the corresponding backplate. Save the screw for use in Step 6.
<Note>
i. Do not install the Fiber Adapter in a shared PCI slot. Avoid any PCI slot next to
an ISA slot because this is often a shared slot and does not support bus
mastering.
ii. If you are going to install the Remote Wake-Up cable, choose an available
PCI slot most close to the 3-pin Remote Wake-Up connector on the PC
motherboard.
iii. If you have problems in identifying a suitable slot, check your PC
documentation or ask your system administrator for help.
Step 5: Carefully insert the Fiber Adapter into the chosen slot and press firmly
with proper push to ensure it is fully seated in the slot.
Step 6: Secure the Fiber Adapter with the screw you saved in step 4.
<Note>
If you wish to use the Remote Wake-Up function, please complete the
installation in next section “Connecting the Remote Wake-Up Cable” before
proceeding to step 7.
Step 7: Replace the PC cover.
Step 8: Proceed to “Connecting to Your Network” section.
