Fiber Ethernet Adapter
14 User’s Guide
Run Diagnostics
Step 1: Choose “Run Diagnostics” from the Main Menu. Press <ENTER>.
Step 2: Select a test or diagnostics, and press <ENTER> to run:
--> Run EEPROM Test
--> Run Diagnostics On Board
--> Run Diagnostics On Network (requires twoTE100PCIFXplus on the
same network. Set one as “Initiator” and the other as “Responder”).
--> Run Power Management Test (also requires two TE100PCIFXplus.
Set one as Target and then power down the computer to “power down
mode. Set the other as Master, specifies the target machine’s Node ID
(MAC address), and send magic packet or wake-up frame to remotely
wake up the target machine.
Step 3: Press <ESC> to exit.
<Note>
i. This program MUST be run under pure DOS mode.
ii. This program MUST run without any network driver installed to prevent any error.
iii. Hit F1 key for additional help.
