English
7
5. Verify that the following panel lights
are on: System Power, PoE
Status and Link/ACT.
Using a non-PoE device with the TPE-S44 and
the TPE-102S
2. Connect an Ethernet cable from a
PoE port (1~4) on the TPE-S44
switch to the POE IN port on the
TPE-102S.
3. Connect an Ethernet cable from a
non-PoE device to the DATA OUT
port on the TPE-102S.
4. Connect the provided Jumper
cable to a non-PoE device (e.g.
TV-IP100) and to the TPE-102S.
1. Select the proper voltage (5V or
12V).
