8
Technical Specifications
General
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
ANSI/IEEE 802.3 NWay Auto-negotiation
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3af Power over Ethernet
Protocol
CSMA/CD
Data Transfer Rates
Ethernet:
10Mbps (half-duplex), 20Mbps (full-duplex)
Fast Ethernet:
100Mbps (half-duplex), 200Mbps (full-duplex)
Network Cables
Ethernet:
UTP/STP CAT-3, -4, -5 ; up to 100M
Fast Ethernet:
UTP/STP CAT-5, -5e, -6; up to 100M
Number of Ports
PoE Power on RJ-45
LED
4 × 10/100Mbps Auto-MDIX RJ45 ports with
PoE enabled (port 1 ~ port 4)
4 × 10/100Mbps Auto-MDIX RJ45 ports
(port 5 ~ port 8)
Power+: pin 3 & pin 6
Power-: pin 1 & pin 2
Per Unit: System Power; PoE Max
Per 10/100 Port: Link/ACT, 100
Per PoE Port: PoE Status, Link/ACT, 100
Topology
Star
