de_top
Top starting point
de_bottom
Bottom Ending point
【Example】<rcpm, 4>
To read the parameters of input channel 4
12. Modifying the input channel parameters
Instruction
Format
<wcpm, SourceChl, contrast, brightness, freq, phase, de_left, de_right, de_top,
de_bottom>
Function
To modify the input channel parameters
Parameters
SourceChl
The input channel, begins from 1.
contrast
brightness
freq
Sampling frequency
phase
de_left,
Left side starting point
de_right
Right side ending point
de_top
Top starting point
de_bottom
Bottom Ending point
【example】<wcpm, 4, 128, 128, 1904, 0014, 0384, 1824, 0031, 0931>
To modify the parameters of input channel 4, contrast is 128, brightness is 128,
sampling frequency is 1904, left starting point is 0014, right ending points is 1824, top starting
point is 0031, and bottom ending point is 0931.
13. Factory reset of VGA input channel
Instruction
Format
<scpm, SourceChl>
Function
Factory reset the VGA input channel
Parameters
SourceChl
The input channel, begins from 1.
【Example】<scpm, 4>
To facotory set the input channel 4
