14. Setting the output displaying mode
Instruction
<tmod, Screen_ID, Mode, grid, R, G, B>
Function
To set the output displaying mode among normal mode, grid mode, and color test
mode.
Parameters
Screen_ID
The video-wall ID
Mode
0: normal displaying mode 1:grid mode 2: pure colour mode
Grid
The spacing between adjacent lines in grid mode
R, G, B
The RGB color space value of the pure colour mode
15. Enabling the video-wall
Instruction
Format
<sena, Screen_id, Screen_en>
Function
Enabling or disabling the video-wall
Parameters
Screen_ID
The video-wall ID
Screen_en
1: video-wall enabling 0: video-wall disabling
【Example】<sena,1,1>
Enabling the video-wall 2.
16. Inquiring the information of video-wall
Instruction
Format
<winf, Screen_ID>
Function
Inquiring the information of video-wall
Parameters
Screen_ID
The video-wall iD
