Locking and unlocking confirmation−
• After locking either the entry door or compartment doors from e-FOB transmitter, the
headlights flash once and the siren sounds once. When the entry door and
compartment doors are both locked within one minute, the headlights flash and siren
sounds twice.
• Locking and unlocking confirmation is deactivated while engine is running.
• Confirmation may be shut off (see page 8).
Door Ajar Confirmation
– A triple siren chirp sounds if any compartment or entry door is
open when the entry and compartment doors are locked. If a door is open, the alarm is not
armed.
The following table describes audio/visual activations at various conditions.
Outputs
Single Lock
confirmation
All Lock
confirmation
Alarm
Siren
Not used Not used 1 minute or when shut off
Horn
1 chirp 2 chirps Not used
Headlights
1 flash 2 flashes 1 minute or when shut off
Deactivate Lock Confirmation – The system defaults to confirmation ON with power-up.
Horn and headlight confirmation can be toggled off and on from the keypad.
1. Enter valid access code.
2. Hold down (9 / 0) button until double beep sounds. Release.
3. Press (1 / 2) button.
Unidirectional actuation pulse output (door opening, battery disconnect, etc.)− The J14
connector (Zone 6) actuation output provides a short pulse when it is activated via a vehicle
switch, keypad (depends on system configuration), or FOB transmitter (depends on I/O
module DIP switch #4 setting). This short pulse output is prohibited while the engine is
running.
Panic mode−(Not a standard function) Available when DIP Switch 4 is ON. Pressing and
holding the Cargo Lock Button of the e-FOB transmitter for 2 seconds activates panic mode.
During panic mode, siren is continuously activated and headlights flash for a maximum of 1
minute. Unlocking the vehicle via the FOB transmitter deactivates panic mode.
Compartment door control is eliminated while in panic mode.
Alarm mode−After locking entry and compartment doors, the system is armed. The alarm is
activated when entry door or compartment doors are opened, or by grounding the extra
security input. The extra security input could be connected to external shock sensing, motion
detection or other sensing device. When alarm is triggered, the siren is continuously
activated and headlights flash for 1 minute. Unlocking doors via FOB transmitter, keypad,
interior switch or starting the engine deactivates alarm mode.
Timed dome/porch light activation−The dome/porch light is activated upon pressing any
keypad button or by unlocking entry door via FOB transmitter. The activation duration is
controlled via trim pot A (see page 6). Starting the engine deactivates the light.
