1
CONTENTS Page
1.0 OVERVIEW 2
1.1 Model number designation 3
1.2 Specifications 4
1.3 Operating principle 5
2.0 INSTALLATION 6
2.1 Orientation 6
2.2 Meter location 6
2.3 By-pass installation 6
2.4 Strainers 6
2.5 Commissioning 7
2.6 Reverse flow (Bi-directional flow) 7
3.0 ELECTRICAL CONNECTIONS 8
3.1 Instrument cable 8
3.2 Pulse output selection 8
3.3 Pulse output boards 9
3.4 Output schematic 9
3.5 Hazardous area wiring 10
4.0 MAINTENANCE 11
4.1 Dismantling 11
4.2 Inspecting 11
4.3 Re-assembling 11
5.0 CLEANING IN-SITU 11
6.0 SPARE PARTS 12
6.1 Spare parts list 12
6.2 Spare parts diagram 13
6.0 SPARE PARTS 12
Description MP015 MP025 MP040 MP050
1
Piston
PEEK 60ºC * SA1514 * SA2514 * SA4014 * SA5014
PEEK 120ºC * SA1515 * SA2515 * SA4015 * SA5015
R
PEEK 150ºC * SA1528 * SA2528 * SA4028 * SA5028
E
CFT 60ºC * SA1516 * SA2516 * SA4016 * SA5016
C
CFT 120ºC * SA1517 * SA2517 * SA4017 * SA5017
O
2 Partition
M
ceramic MC1516 MC2516 MC4016 MC5016
M
st ainless steel SA1519 SA2519 SA4019 SA5019
E
3 Manifold bearing
N
PEEK BG MC1510 MC2510 MC4010 MC5010
D
CFT MC1511 MC2511 MC4011 MC5011
E
4
Manifold O-ring
D
vit on SC1514 SC2514 SC4014 SC5014
EPR SC1515 SC2515 SC4015 SC5015
S
t eflon SC1516 SC2516 SC4016 SC5016
P
buna-N SC1513 SC2513 SC4013 SC5013
A
5
Pulse output board
R
st ainless / aluminum * SA1505 * SA2505 * SA4005 * SA5005
E
High pressure * SA1506 * SA2506 * SA4006 -
S
High temp. 150ºC (Hall) * SA1503 * SA2503 * SA4003 * SA5003
*
Add the suffix " Q" to t he appropriate part number f or Quadrature output spares,
this applies only to flow meters supplied w ith Bi-directional flow output part s.
6 Output board screw
SC0002 SC0002 SC0002 SC0002
7
Terminal cover
st ainless steel SA0001 SA0001 SA0001 SA5001
aluminium SA0002 SA0002 SA0002 SA5002
GRN glass re-inforced SA0003 SA0003 SA0003 SA5003
8 Terminal cover screw
st ainless / aluminum SC0001 SC0001 SC0001 SC0001
9
Terminal cover O-ring
f or SS & alum. covers SC0012 SC0012 SC0012 SC0012
f or GRN covers SC0013 SC0013 SC0013 SC0013
10 Body
st ainless steel SA1510 SA2510 SA4010 SA5010
high pressure stainless SA1511 SA2511 SA4011 -
aluminum SA1512 SA2512 SA4012 SA5012
11 Body screw
st ainless / aluminum SC0003 SC0003 SC4003 SC5003
high pressure SC0020 SC0020 SC4020 -
12 Manifold
st ainless (BSP) SA1520 SA2520 SA4020 SA5020
st ainless (NPT) SA1521 SA2521 SA4021 SA5021
aluminium (BSP) SA1524 SA2524 SA4024 SA5024
aluminium (NPT) SA1525 SA2525 SA4025 SA5025
Part Numbers
Item
