3. INSTALLATION
3.1 Mounting
Page 15
6. PROGRAMMING FLOW CHART
6.1 Program levels 8 ~ 12
42.6 mm
( 1.67 ” )
Surface mount footprint
( 4 x M4 screws supplied )
RATE TOTALISER
RATE
TOTAL
ACCUM
TOTAL
^
RESET
>
PROGRAM
ENTER
gal
RUN ACCUM. TOTAL STOP BAT LOW HIGH
RATE TOTALISER
RATE
TOTAL
ACCUM
TOTAL
^
RESET
>
PROGRAM
ENTER
gal
RUN ACCUM. TOTAL STOP BAT LOW HIGH
MP040
Integral meter
mounts
Wall mount using optional
bracket set ( P/No. AWM )
PROG
TIP: holding the prog. key for 3 sec’s
quick tracks to the END of the program
L8 SET RATE DAMPENING
DAMP 00 ~ 99 RATE
program returns to end or advances
to next level if model RT12
1) Any number up to 10 frequency points of non-
linearity can be programmed with point 0F being
the pulse output frequency at the lowest flow rate.
2) If any frequency point is set to zero Hz then
all remaining NLC points up to point 9F will
automatically assume the last entered NLC
K-factor and the program will advance to the
next level. This feature simplifies programming
when not all points of correction are used.
3) Linear interpolation is used between frequency
points, except above the last entered frequency
where the last entered NLC K-factor is applied.
Non-linear correction (NLC)
( overrides K-factor set at L4 )
1) ULTRA POWER SAVE
2) STANDBY
3) CONTINUOUS
( refer clause 4.7 )
L12 CHANGE POWER MODE Y / N
CHANGE Y / N
YES
continued if
model RT12
NO YES
9F 0000.0 (set output freq. at point 9)
000000.000 ( set K-factor at point 9 )
10 points from 0F up to 9F
L11 NON LINEAR CORRECTION
NLC Y / N
0F 0000.0 (set output freq. at point 0)
000000.000 ( set K-factor at point 0 )
1F 0000.0 (set output freq. at point 1)
000000.000 ( set K-factor at point 1 )
YES
L9 OUTPUT PULSE REQUIRED Y / N
PULSE Y / N
NO
L10 ENTER No. OF gal - litres etc
PER OUTPUT PULSE
OP XXXX . X
Program level L12 (power mode)
does not appear if the RT is
externall
y
dc
p
owered
NO
TP050
RATE TOTALISER
RATE
TOTAL
ACCUM
TOTAL
^
RESET
>
PROGRAM
ENTER
gal
RUN ACCUM. TOTAL STOP BAT LOW HIGH
42.6 mm
( 1.7 ” )
18 mm
( 0.7 ” )
80 mm ( 3.15 ” )
program return
