Trimec rt11 - Pipe Mount; Panel Mount

14 Programming
6. PROGRAMMING FLOW CHART
6.1 Program levels 1~7 (RT11 & 12)
Installation 7
3.1 Mounting (continued)
press Prog. key
to step through
program levels
PROG
continued
program return
if PIN protected
L3 SET ENGINEERING UNITS
ENG UNIT Ltr gal m3 Ibs kgs (none)
L2 RESET ACCUM TOTAL Y / N
RESET Y - N
L5 SET DECIMAL POINTS
DPt TOTAL 0 0.0 0.00 0.000
DPt ACCUM TOTAL 0 0.0 0.00 0.000
DPt RATE 0 0.0 0.00 0.000
L1 CHANGE PIN No. Y / N
NU PIN Y - N
PIN * * * *
YES
NO
L4
ENTER NUMBER PULSES PER
Ltr m3 kg gal Ib (unit of measure)
0000000.001 ~ 9999999.999
Saves & exits program
YES
L7 SET TIME BASE FOR RATE
Ltr gal etc / SEC MIN HR or DAY
L6 RATE CONVERSION Y / N
RATECON Y - N
NO
RT11 V3.0 HOLD 3 2 1
PROGRAM MODE ENTERED
TESTING DISPLAY 88888888
INVALID PIN VIEW
EXISTING PROGRAM
DETAILS ONLY
if incorrect
PIN No. is entered
K
-
factor
(scale factor)
is the number of
pulses per unit volume or unit mass
eg: 20.465 pulses / litre, gallon, kg etc.
R 0000.001 ~ 9999.999
WARNING
on rate con
version factor (RCF)
This feature need only be programmed when
the total & rate engineering units are to be
different. eg: m3 for total and litres for rate
The conversion factor is the number needed
to convert to the required rate unit, some
examples are:
Total unit
Rate unit
Conversion factor
Cubic metres
US Barrels
Imp. gallons
1000.000
42.000
4.546
Litres /
USgal /
Litres /
PROG
RATE
END
Y - N
NO
YES
hold Program & Rate
keys for 5 secs to
enter the program
PIN
* * * *
ENTER PIN
* order Pipe mount kit P/No. APM
comprising two brackets,
screws and worm drive clamps.
Conduit entries have an integral
moulded seal, to remove break
seal out using suitable lever
( eg. screwdriver or rod )
* Horizontal
pipe mount
* Vertical pipe mount
RATE TOTALISER
RATE
TOTAL
ACCUM
TOTAL
PROGRAM
ENTER
gal
RUN ACC
UM. TOTAL
STOP BAT LOW HIGH
RESET
Panel mount
Cut a 106.5mm (4.2 ”)
diameter hole in panel
