Introduction
Entity is based on proven microcontroller technology with front end ASICs, resulting in
compact and accurate energy metering. The accuracy of the meters is maintained
even under severely distorted waveform conditions which occur due to harmonics in
the system.
Entity is a low cost effective, easy user interface and can measure accurate KWh
energy that displays on 16X1 LCD. The unit supports only for three phase four wire in
an electrical installation.
The Main Features Available in This Model:
•
Class 1.0S accuracy as per IS13779
•
Class 0.5S accuracy also available
•
Compact 96 x 96 x 55 mm enclosure
•
Microcontroller based with true RMS measurement
•
16X1 LC display
•
Measurement of KWh,KVAh and KVARh Energy (3 Energy)Variant available
without RS485.
