Tripp Lite B032-DUA2 User Manual

8
Operation
6. After the upgrade has completed, a screen appears to inform you that the
procedure to upgrade was successful. Click Finish to close the Firmware
Upgrade Utility.
7. Set up your KVM installation again.
Firmware Upgrade Utility-Failed
If the Upgrade Succeeded screen does not appear, it means that the
upgrade failed to complete successfully, in which case you should do the
following:
1. Disconnect the USB connectors on the KVM cables from the computer.
2. Press and hold the Remote Port Selector’s pushbutton. While still
pressing the pushbutton, reconnect the KVM cable’s USB connectors to
the computer.
3. Power on the B032-DUA2. It will now work with the factory default
firmware. Follow the steps in the Firmware Upgrade Utility section to
upgrade the firmware.
17-10-486-933633.indb 8 11/17/2017 2:44:37 PM

Tripp Lite B032-DUA2 Specifications

General

Console ports	3.5mm headphone
Audio connections	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of computers controlled	2
Certification	CE, FCC, REACH
Product color	Black
Sustainability certificates	RoHS
Built-in display	No
Number of users	1 user(s)
Cables included	Audio (3.5mm), DVI, USB
Package depth	238.8 mm
Package width	170.2 mm
Package height	61 mm
Package weight	590 g
Country of origin	China
Master (outer) case width	497.1 mm
Master (outer) case height	196.1 mm
Master (outer) case length	327.9 mm
Master (outer) case weight	7080 g
Harmonized System (HS) code	8471.80.1000
Quantity per master (outer) case	10 pc(s)
Master (outer) case GTIN (EAN/UPC)	10037332200362
