Installation
1
Before mounting the remote to a permanent location, ensure the 20 ft. (6 m) remote
cable can reach the inverter’s RJ11 remote port.
2
The following mounting dimensions should be used when installing the remote to a
permanent mounting location:
2.539 in. (65 mm)
Ø0.157 in. (4 mm)
3.818 in. (97 mm)
4.284 in. (109 mm)
0.104 in. (3 mm)
Ø1.269 in. (32 mm) 0.492 in. (13 mm)
STATUS
ON/OFF
PINVRM
