mini exposed sequential thermostatic mixer shower
1
1
2
3
4
5
6
7
Fig.1
Main components
MAIN COMPONENTS
Ref Description
1. Control knob 5. Mounting plate
2. Mixer shower valve 6. Inlet nut and olive X2
3. Blanking plug 7. Wall trim X2
4. Outlet adapter
