Thermostatic mixer shower
8
FITTING THE MIXER
Mark the position of the locating screws for the
mounting plate.
Drill and plug the wall.
(An appropriate drill bit should be used. If the
wall is brick, plasterboard or a soft building block,
appropriate wall plugs and screws should be
fitted).
Fit the mounting plate onto the wall (fig.9).
The inlet elbows allow for either rising, falling
or rear entry hot and cold water supplies. The
elbows have two ‘O’ ring seals (fig.10) to the
body and do not require PTFE tape or other
means of sealing.
IMPORTANT:
Make sure that all the supply pipework has
been flushed through before fitting the mixer
(fig.11).
‘O’ rings
Fig.11
Fig.9
Fig.10
