Trance 2nd generation electric shower
12
Screw the top fixing and bottom screws into
position leaving the base of the screw heads
protruding 6mm out from the wall.
Hook the backplate over the top and bottom
screws and fit the centre fixing screw into
position. Do not fully tighten the screws at this
stage, as the fixing holes are elongated to allow
for out of square adjustment after the plumbing
connections have been completed.
T00434
P12721002AP12721002A
INLETINLET
>POM-GF30<
>POM-GF30<
P12721002A
INLET
Fig.11
Fig.10
