Trance 2nd generation electric shower
20
T00396
Filter
Fig.26
G-003-A
It is recommended that the lter is periodically
cleaned in order to maintain the per
formance of
the shower
. It is essential that this operation is
carried out by an installer or ser
vice engineer.
IMPORT
ANT: Before ser
vicing, switch off both
the electricity supply and water supply at the
mains.
The inlet lter is situated in the side of the inlet
pipe
(g. ).
T
o gain access to the lter, remove the trimplate
and then unscrew the retaining nut from the side
of the inlet pipe.
W
hen cleaning the lter, do not use a sharp
object as it will cause damage. It is preferable to
use an old toothbrush or similar
.
W
hen retting the lter Do Not overtighten the

lter cap.
Cleaning the inlet filter
CLEANING THE INLET FILTER
26
ENTRY POINTS
Diagram Key:
Water
Entry Points
Cable
Entry Points
WARNINGWARNING
WARNING
P12721002AP12721002A
INLETINLET
>POM-GF30<
>POM-GF30<
P12721002A
INLET
INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY
