Triumph Bonneville Bobber 2018 User Manual

Maintenance
94
Warning
If the ABS is not functioning, the brake
system will continue to function as a
non-ABS equipped brake system. In
this situation, braking too hard will
cause the wheels to lock resulting in
loss of control and an accident.
Reduce speed and do not continue to
ride for longer than is necessary with
the indicator light illuminated. Contact
an authorised Triumph dealer as soon
as possible to have the fault checked
and rectified.
Inspect the level of brake fluid in both
reservoirs and change the brake fluid in
accordance with scheduled maintenance
requirements. Use only DOT 4 fluid as
recommended in the Specification
section. The brake fluid must also be
changed if it becomes, or is suspected of
having become contaminated with
moisture or any other contaminants.
Note:
• A special tool is required to bleed
the ABS braking system. Contact
your authorised Triumph dealer
when the brake fluid needs
renewing or the hydraulic system
requires maintenance.
Front Brake Fluid Level Inspection
and Adjustment
Inspect and adjust the brake fluid level
as described below.
1
2
1. Upper level line
2. Lower level line
To inspect the front brake fluid level:
• Check the level of fluid visible in
the window at the front of the
reservoir body.
• The brake fluid level must be kept
between the upper and lower level
lines (reservoir held horizontal).
To adjust the brake fluid level:
• Release the cap retaining screws
and remove the reservoir cap and
the diaphragm seal.
• Fill the reservoir to the upper level
line using new DOT 4 brake fluid
from a sealed container.
• Refit the reservoir cap making sure
that the diaphragm seal is correctly
positioned between the cap and
reservoir body.
• Tighten the cap retaining screws
to 1 Nm.

Triumph Bonneville Bobber 2018 Specifications

General

Engine Displacement	1200 cc
Compression Ratio	10.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Transmission	6-speed
Frame	Tubular steel cradle
Front Tyre	100/90-19
Rear Tyre	150/80 R16
Seat Height	690 mm
Trail	90 mm
Dry Weight	228 kg
Engine Type	Liquid-cooled, 8 valve, SOHC, parallel twin
Bore x Stroke	97.6 mm x 80 mm
Power	76 HP (55 kW) @ 6, 100 rpm
Torque	106 Nm @ 4, 000 rpm
Final Drive	Chain
Swingarm	Twin-sided, steel
Front Wheel	19 x 2.5 in
Rear Wheel	16 in
Front Suspension	41mm forks
Front Brakes	Single 310 mm disc, 2-piston caliper
Rear Brakes	Single 255 mm disc, 2-piston caliper
Instrument Display and Functions	LCD multi-functional instrument pack with analogue speedometer, odometer, gear position indicator, fuel gauge, range to empty, service indicator, clock, trip computer, scroll and mode buttons on handlebar, cruise control, traction control status, heated grip ready, and throttle mode display
Wheelbase	1, 510mm
Tank Capacity	9.1 L (2.4 US gal)
Exhaust	Brushed 2-into-2 with twin slash cut silencers
