Triumph Tiger XCX - Heated Seats (if Equipped)

General Information
106
Heated Seats (if equipped)
The heated seats switch (if equipped) is
located on the left hand side hand grip.
The heated seat switch operates both
the rider and passenger heated seats.
1
1. Heated seat switch
The heated seats will only heat when
the engine is running. When the heated
seats are switched on, the heated seats
symbol will appear in the display. The
selected heat level for each seat will
also be indicated by the color of the
symbol.
1 2
1. Low heat symbol (amber)
2. High heat symbol (red)
o7:29
12.5
1
9999 02:25
8
6
4
2
0
12
14
25.2
F
E
TRIP
mi mp/hHH:MM
PM
RPM
x1000
10
1
N
2
1. Rider’s heated seat (high heat selected)
2. Passenger’s heated seat (switched on)
