Triumph Tiger XCX - Stopping the Engine

How to Ride the Motorcycle
119
Stopping the Engine
Tiger 800 XR Model Only
P
U
S
H
O
F
F
O
N
5
6
TC
TC
8
2
4
3
1
7
1. Engine stop switch
2. STOP position
3. RUN position
4. Starter button
5. Ignition switch
6. OFF position
7. ON position
8. Neutral indicator light
All Models except Tiger 800 XR
P
U
S
H
O
F
F
O
N
5
6
7
8
6
4
2
0
12
14
RPM
x1000
10
N
8
2
4
3
1
1. Engine stop switch
2. STOP position
3. RUN position
4. Starter button
5. Ignition switch
6. OFF position
7. ON position
8. Neutral indicator light
To stop the engine:
• Close the throttle completely.
• Select neutral.
• Turn the ignition switch OFF.
• Select first gear.
• Support the motorcycle on a firm,
level surface with the side stand.
• Lock the steering.
Caution
The engine should normally be stopped
by turning the ignition switch to the
OFF position. The engine stop switch is
for emergency use only.
Do not leave the ignition switched on
with the engine stopped.
Electrical damage may result.
