PARTS IDENTIFICATION
Tiger 800 XR Models
2 3
4
5
6
7
14
13 12 10 915
1
11
8
1. Headlight
2. Front turn signal
3. Electrical accessory socket
4. Fuel tank and fuel filler cap
5. Battery and fuse boxes (under the
rider seat)
6. USB socket (under the passenger seat)
7. Tool kit/Accessory U-lock storage
location (under the passenger seat)
8. Seat lock
9. Rear wheel adjuster
10. Drive chain
11. Center stand (if equipped)
12. Side stand
13. Gear shift pedal
14. Front brake caliper
15. Front brake disc
To Next Page
