Parts Identification
17
Tiger 800 XR Models (continued)
2 3 6 7 84
16
15 14 13 1118 17
1
10
95
12
1. Tail/brake light
2. Rear brake fluid reservoir
3. Oil filler cap
4. Coolant expansion tank
5. Handguards (if equipped)
6. Mirror
7. Headlight adjuster
8. Windshield
9. Fog light (if equipped)
10. Front fork
11. Radiator/Coolant pressure cap
12. Clutch cable
13. Engine oil level sight glass
14. Rear brake pedal
15. Rear suspension spring preload adjuster
16. Rear brake caliper
1 7. Rear brake disc
18. Rear turn signal
