Tiger 800 XC Models (continued)
2
3 6
7
8
4
15
14
13 12
11
17
16
1
10
5
1819
9
1. Tail/brake light
2. Rear brake fluid reservoir
3. Oil filler cap
4. Coolant expansion tank
5. Handguards
6. Mirror
7. Headlight adjuster
8. Windshield
9. Fog light (if equipped)
10. Front fork
11. Radiator/Coolant pressure cap
12. Clutch cable
13. Engine oil level sight glass
14. Rear brake pedal
15. Rear suspension preload adjuster
16. Rear suspension rebound damping
adjuster
1 7. Rear brake caliper
18. Rear brake disc
19. Rear turn signal
