Parts Identification
21
Rider View Parts Identification
All Models except Tiger 800 XR
12 3 4 5 68
9
7
10
1112131415
1617
18
ckec
1. Clutch lever
2. Headlight dimmer switch
3. Heated seats switch (if equipped)
4. Fog lights switch (if equipped)
5. Cruise control adjust switch
6. TFT instrument display
7. Front brake fluid reservoir
8. Hazard warning light button
9. Front brake lever
10. Engine start/stop button
11. HOME button
12. Ignition switch
13. Electrical accessory socket
14. MODE button
15. Joystick button
16. Turn signal switch
17. Horn button
18. Daytime Running Lights (DRL)
(if equipped)
