Triumph Trident - Page 141

MAINTENANCE
141
Tiger Sport Fuse Box 1
20A
15A
10A
15A
10A ACC
15A
10A
15A
1
2
3
4
5
6
7
8
9
Tiger Sport Fuse Box 1
Position Circuit Protected
Rating
(Amps)
1 Ignition 15
2
Starter Motor and
Cooling Fan
15
3 Instruments 10
4 Fuel Pump 10
5 ABS Solenoid 15
6 ABS Pump 20
7 Accessory 10
8
Engine Management
System (EMS) 1
15
9 Empty -
Tiger Sport Fuse Box 2
USB
5A
3A
3A
3A
3A
5A
1
2
3
6
7
8
4
5
9
Tiger Sport Fuse Box 2
Position Circuit Protected
Rating
(Amps)
1
Main Beam and Fog
Lights
5
2 Dipped Beam 3
3 USB 3
4 Empty -
5 Empty -
6 Horn 5
7 Run/Stop Switch 3
8 Position Lighting 3
9 Empty -
