PARTS LIST
No. Description Qty
1 Main Frame 1
2 Frame Base 1
3 Right Handrail 1
4 Left Handrail 1
5 Console Support 1
6 Outer Slide (Lower) 1
7 Inner Slide 1
8 Inclination Adjustor Bar 1
9 Motor Bracket 1
10 Locking Knob Axle 1
11 Belt Guide 2
12 Front Iron Sheet (65 × 29.4 × 2T) 2
13 Motor 1
14 Drive Belt 1
15 Running Board 1
16 Running Belt 1
17 Front Roller W/Pulley 1
18 Rear Roller 1
19 Frame Cover 1
20 Console Assembly 1
20-1 Top Console Cover 1
20-2 Bottom Console Cover 1
20-4 Safety Switch Module W/ Cable 1
20-8 Self Tapping Screw (3 × 10 mm) 2
20-9 Self Tapping Screw (3.5 × 12 mm) 9
21 Top Motor Cover 1
22 Top Motor Cover Plate 1
23 Beverage Holder 1
No. Description Qty
24 Inclination Adjustor Bushing 2
25 Rear Adjustment Base (L) 1
26 Rear Adjustment Base (R) 1
27 Motor Cover Anchor 4
28 Transportation Wheel 2
29 Transportation Wheel End Cap (30 x 60) 2
30 Foot Pad 2
31 Foot Rail 2
32 Handgrip Cap 2
33 Square End Cap (25 x 50) 2
34 Indentation End Cap 2
35 Isolator 2
36 Inclination Adjustor (L) 1
37 Inclination Adjustor (R) 1
38 Wire Protective Rubber 1
39 Non-Slip Rubber (L) 1
40 Non-Slip Rubber (R) 1
41 Grommet 1
42 Magnet 1
43 Handgrip Foam 2
44 Safety Key 1
45 Console Cable (Upper) (900 mm) 1
46 Console Cable (Lower) (1500 mm) 1
47 Connecting Wire (Black) (10 cm x 764 x 764) 1
48 Connecting Wire (White) (15 cm x 764 x 764) 1
49 Connecting Wire (Black) (15 cm x 764 x 764) 1
50 Controller 1
51 Breaker 1
To Next Page
