ASSEMBLY STEPS
STEP 54:
1. Slide a Weight Bumper (37) onto each storage
tube on the Left Support (6).
Make sure that the at edge of each
Weight Bumper is facing away from the
Left Support.
2. Slide a Weight Bumper (37) onto each
storage tube the Right Support (not shown).
STEP 54
37
6
STEP 55:
1. Set a Barbell Rest (35) and a Barbell Spotter (36)
on the Left Upright (3).
Set the other Barbell Rest and the other
Barbell Spotter on the Right Upright (not
shown).
2. Make sure that both Barbell Rests (35) and
both Barbell Spotters (36) are set at the
same height.
STEP 55
36
3
35
37
35
36
3
