HARDWARE & TOOLS LIST
INSTRUCTIONS FOR ASSEMBLY
• Before you start to assemble, please check the hardware packaging to make sure all parts are included.
•
Basic tools, such as spanners will be provided for assembly.
4. (M8 x 55 mm) (8 PCS)
5. (D8) (8 PCS)
6. (D8) (20 PCS)
7. (M4 X 10 mm) (2 PCS)
11. (M8 X 50 mm) (4 PCS)
12. (M5 X 10 mm) (2 PCS)
25. (M8 X 50 mm) (2 PCS)
26. (M8 X 35 mm) (4 PCS)
32. (M5 X 10 mm) (2 PCS)
72. (ST4.2 X 20 mm) (2 PCS)
75. (M8 X ST4.2 X 20 mm) (6 PCS)
(S13, 14, 15) (1 PC)
(S6) (1 PC)
