Trojan ORBIT 250 - PARTS LIST

7
No. Description Qty
1 Console 1
2 Screw (M5) 2
3 Pulse 2
4 Middle Handlebar 1
5 Screw (ST4.2X19) 2
6
End Cap (
ø25)
2
7 Small Cover 1
8 Bolt (M8 x 30) 2
9 Spring Washer (D8) 4
10 Foam Grip 2
11 Handlebar (L/R) 2
12 Foam Grip 2
13
End Cap (
ø28)
2
14
Stopple (
ø12.6 X ø6)
2
15 Upright Post 1
16 Wire 1
17 End Cap (S13) 2
18 Bolt (M8 x 16) 2
19
Washer (D8 X
ø32 X 2)
2
20
Bushing (
ø32 X ø19 X 28)
4
21 Bolt (M8 x 40) 4
22
Arc Washer (D8 X
ø20 X 2 X R30)
8
23 Domed Nut (M8) 8
24 Plastic Insert 2
25 Lower Handlebar (L/R) 2
26 Bolt (M8 x 16 x S6) 4
27 Water Bolt Cage 1
28 End Cap (S17) 6
29 Bolt (M10 x 60) 2
No. Description Qty
30
Bushing (
ø14 X 12.5 X ø10.1)
8
31
Washer (D10 X
ø20 X 2)
4
32 Nylon Nut (M10) 8
33 Carriage Bolt (M8 X 60) 4
34
End Cap (
ø60)
2
35 Front Stabiliser 1
36 Rear Stabiliser 1
37
End Cap (
ø60)
1
38 Sensor 1
39 Tension Wire 1
40 Main Frame 1
41 End Cap (J40 X 25) 4
42 Pedal Tube (L/R) 2
43 Bolt (M10 X 45) 4
44 Pedal 2
45 Bolt (M10 X 50) 2
46 Bolt (L/R 1/2’’) 2
47 Arc Washer (D17) 2
48
Bushing (
ø24 X 20 X ø16.1)
4
49 U Bracket (L/R) 2
50 Spring Washer (1/2’’) 2
51 Nylon Nut (L/R 1/2’’) 2
52 Plastic Ring 2
53 Tension Control 1
54 Screw (M5) 1
55 Arc Washer (D6) 1
56 Small Cover 1
57 Screw (ST4.2 X 19) 1
58
Arc Washer (D8 X
ø16 X 1.5 X R30)
4
PARTS LIST
