Trojan PRO Series - Step 3

14
STEP 3:
STEP 3
ASSEMBLY STEPS
Connect the Upper console wire (E03) to the Lower console wire (E04) as shown in the illustration.
Use the #5 Allen key (B17) to fix the Handlebar assembly (F) to the Handlebar tube (A02) using 4 x Cylindrical
head screw (M6 x 12 mm) (D12). Do not damage the Upper and lower console wires.
Use the Cross wrench (B18) to attach the Left Pedal (C50) to the Left crank (B01).
Use the Cross wrench (B18) to attach the Right Pedal (C51) to the Right crank (B02).
Use the Cross wrench (B18) to fix the Front stabilizer cover (C34) to the Front stabilizer (B) using 1 x Pan
head screw (M5 x 10 mm) (D08)
