PARTS LIST
No. Description Qty
1 Main Frame 1
2 Handlebar 1
3 Handlebar Post 1
4 Rear Stabiliser (Ø50 x 1.5) 1
5 Magnetic Wheel (Ø180 × 25) 1
6 Front Stabiliser (Ø50 x 1.5) 1
7 Tension Control Knob 1
8 Seat Height Adjustment Knob (M16) 1
9 Belt (290 / J4) 1
10 Console 1
11 Magnetic Bracket 1
12 Seat Post Plastic Bushing 1
13 Left Chain Cover 1
14 Spring (65 Mn / Ø10 × 50 x Ø1.0) 1
15 Cross Pan Head Tapping Screw (ST2.9 × 9.5) 2
16 Flat Washer (Ø23 × Ø35 × 2.0) 1
17 Puller Bushing (7/8”) 1
18 Hexagon Bolt 1
19 Belt Pulley with Crank (6”) 1
20 Left Foot Pedal (1/2”) 1
21 Right Foot Pedal (1/2”) 1
22 Bearing Bush (Ø55.6 × 16) 2
23 Bearing (Ø44.5) 2
24 Hexagon Bolt (M8 × 15) 6
25 Seat Post 1
26 Sensor with Wire (L = 350 mm) 1
No. Description Qty
27 Seat Cushion 1
28 Front Stabiliser End Cap 2
29 Rear Stabiliser End Cap 2
30 Magnetic Wheel Axle (Ø17 × 90) 1
31 Bearing (6203 Z) 2
32 Curve Washer (Ø17) 1
33 Nylon Nut (M6) 1
34 Cap Nut (M10) 4
35 Bolt (M10 x 56) 4
36 Arc Washer (Ø10 x Ø20 x 1.5) 4
37 Curve Washer (Ø8) 6
38 Flat Washer (Ø8 x Ø20 x Ø1.5) 3
39 Hexagon Bolt (M8 × 20) 1
40 Cross Pan Head Tapping screw (ST4.2 × 25) 7
41 Tension Spring (Ø20 × 39 × Ø3.2) 1
42 Nylon Nut (M8) 4
43 Hexagon Bolt (M6 × 20) 1
44 Pressure Plate 1
45 Bearing (6000 zz) 2
46 Arc Washer (Ø5) 1
47 Bushing (Ø21 × Ø15.2 × 3.0) 1
48 Flat Washer (Ø40 × 2.8) 1
49 Handlebar End Cap 2
50 Handrail Arm Foam Grip (Ø21 × Ø27 × 500) 2
51 Cross Pan Head Tapping Screw (ST4.2 × 20) 2
52 Circlip (Ø10) 1
