Trojan STRIDER 100 User Manual

1567-5
3. HARDWARE LIST
NOTE :
The described parts are all you need to assemble this machine.
Before starting assembly, please check the hardware packing to make sure they are included.
Set No. No.
Description Q'ty
1#
46
Bolt (3/8” x 2-3/8”)
4
47
Nut Cap (3/8")
4
17
Locking Knob
2
Allen Key (M8)
1
Wrench
1
2#
51
Spring Washer (1/2")
2
12B-L
Hinge Bolt (1/2")
1
3#
58
Hinge Screw (3/8" x 20mm)
2
12A
Handle Bar Shaft
1
No.
Description Q'ty
44
Bolt (3/8” x 50mm)
4
45
Nylon Nut (3/8")
4
46B
Curve Washer (3/8")
4
Allen Key (M6)
2
48-R
48-L
Nylon Nut (1/2")
2
12B-R
Hinge Bolt (1/2")
1
49R
49L
D Shape Washer (ø28 x 5mm)
1pc
1pc
52-R
52-L
Spring Washer (M10)
1pc
1pc
