Trojan TR 1500 - Parts List

8
TR 1500 - T
PARTS LIST
No. Description Qty
1 Bottom Frame 1
2 Main Frame 1
3 L/R Upright Tube 2
4 Computer Frame 1
5 Incline Frame 1
6 Strengthening Tube 1
7 Wheel Bracket 2
8 Front Roller 1
9 Rear Roller 1
10 Metal Speaker Grille 2
11 Cylinder 1
12 Transport Wheel Stopper 2
13 D-Shaped Axle 2
14 Transport Wheel Axle 2
15 Spacer 2
16 Edging Fixing 8
17 Motor Cover 1
18 Rear Protective Cover 1
19 l/R Protective Covers 2
20 Computer Upper Cover 1
21 Computer Bottom Cover 1
22 l/R Computer Side Covers 2
23 Computer Panel 1
24 Computer Bottom Panel 1
25 l/R Loudspeaker Covers 2.
26 l/R Upright Tube Covers 1 2
27 l/R Upright Tube Covers 2 2
28 Pu Handlebar Grip 2
29 Front Roller Cover 1
No. Description Qty
30 Running Board 1
31 Running Belt 1
32 Edgings 2
33 Transport Wheel 2
34 End Cap 2
35 Flat Foot Pad 2
36 Square End Cap (Outer) 2
37 Protective Plug 2
38 Cushion 2
39 Power Cord Buckle 1
40 Adjusting Wheel 2
41 Square End Cap (Inner) 2
42 Belt 1
43 Wheel 2
44 Blow Molding Cushion 2
45 Plastic Pad 4
46 Square End Cap (Inner) 2 2
47 Hex Socket Screw M10 x 55 1
48 Hex Socket Screw M10 x 50 2
49 Hex Socket Screw M10 x 40 1
50 Hex Socket Screw M10 x 15 14
51 Hex Socket Screw M8 x 50 4
52 Hex Socket Screw M8 x 45 1
53 Hex Socket Screw M8 x 40 3
54 Hex Screw M8 x 75 1
55 Hex Screw M8 x 50 1
56 Hex Screw M8 x 35 2
57 Hex Socket Head Screw M8 x 18 4
58 Hex Socket Head Screw M6 x 45 1
