Chapter 2: Locations 2902 Walkaround • Owner’s Manual Supplement
Deck Views
CLEAT
FUEL LINES
TO ENGINES
BOW
HATCH
CLEAT
ROD
HOLDER
HAWSE
PIPE
ROD
HOLDERS
HAWSE
PIPE
PORTLIGHTS
ANCHOR
LOCKER
BOW LIGHT
WINDLASS
(IF EQUIPPED)
WINDLASS CONTROLS
(IF EQUIPPED)
CLEAT
CLEAT
FUEL FILL
DECK FITTING
BAITWELL
COOLER
BATTERY SWITCH HATCH
ACCESS HATCH
ACCESS HATCH
GRAB RAIL
RIGGING HOSE
RIGGING
HOSE
COCKPIT SINK LIDSTORAGE HATCHES
WASTE PUMP-OUT DECK
FITTING (IF EQUIPPED)
PORT FISH LOCKER
FISH LOCKER
AIR CONDITIONER
(IF EQUIPPED)
CITY WATER INLET
(IF EQUIPPED)
TRANSOM SHOWER
(IF EQUIPPED)
OIL FILL DECK
FITTINGS
ALL AROUND LIGHT
(IF EQUIPPED)
WATER FILL
DECK FITTING
