52
Chapter 12: Electrical System 2902 Walkaround • Owner’s Manual Supplement
Direct Current Electrical Harness
FORWARD BILGE PUMP
STARBOARD ENGINE
PORT ENGINE
AFT BILGE PUMP
WATER PUMP
TRIM TAB PUMP
FISH WELL
DRAIN PUMPS
